| 類目Category | 描述Descriptions | |
| 型號Model | 序列No. | YL-8502 |
| 核心模塊 Nucleus Module | CPU | Intel? Celeron? Processor J1900 (Quad Core 2M Cache, up to 2.42 GHz) |
| Intel? Celeron? Processor N2930 (Quad Core 2M Cache, up to 2.16GHz) | ||
| Intel? ATOM? Processor E3845 (Quad Core 2M Cache, 1.91GHz) | ||
| 芯片組Chipset | Intel?Bay Trail D/I/M SOC integrated chipset | |
| BIOS | AMI 64Mbit Flash ROM | |
| 內存RAM | Onboard DDR3L 1333MHZ 2GB/4GB /8GB | |
| 硬盤Storage |
1*mSATA slot(32G/64G/128G/256G SSD), 1*SATA bay(7+15P 500G-1T 2.5" HDD), optional | |
| 顯卡Graphic | Integrated Intel?Bay Trail D/I/M SOC | |
| 網卡Network |
2*Intel? Ethernet Controller I211AT 1000M lan (Support Intel? Ethernet Controller I210 Series) | |
| 聲卡Audio | Realtek ALC892 | |
| 接口I/O | 網口Lan | 2*RJ45 (Gigabit Ethernet) |
| USB | 5*USB2.0, 1*USB3.0 | |
| 顯示Display | 1*VGA; 1*HDMI | |
| WIFI | 1*WiFi module with 2 antennas(Optional) | |
| 串口COM | 4*COM(RS232) | |
| 按鈕Button | 1*Power Button | |
| 喇叭SPK | 1* Audio-out | |
| Mic | 1*Mic-in | |
| 擴展Expansion | 1*mini-PCIe (for WiFi and Bluetooth) | |
| 系統OS | Operating System | Windows 7/8/10, Linux |
| 機構Structure | Dissipation | high-quality profile case for quick heat dissipation |
| 外殼Housing | aluminum alloy | |
| Bracket | VESA bracket(Optional) | |
| Dimensions | 134 * 124 * 46mm / 5.28 * 4.88 * 1.81 Inch (WxDxH) | |
| Weight | 0.59KG(N.W.) | |
| 電源Power | DC In | DC 12V-IN power supply and AC power adapter |
| 溫/濕度 Temperature & Humidity | Working Temp. | -40°C~ 65°C (-40°F~149°F) |
| Strorage Temp. | -40°C~ 85°C (-40°F~185°F) | |
| Working Humidity | 10% - 95% relative humidity(Non-condensing) | |
| 認證Cert. | Safety | CE, FCC, RoHS |
| 包裝Packing | 清單Items |
pc, power adapter, power cord, CD driver, VESA Bracket & 2 Antennas(Optional) |
